Plan 535-22

Photographs may show modified designs.
Plan 535-22

Key Specs


8818
sq ft

9
Beds

6
Baths

3
Floors

6
Garages

Plan Description


This 3 unit building is a vision of the future in contemporary living. Each unit is 1,700 s.f. with 3 bedrooms and 2.5 baths. To the left of the entry hall, you will find the great room witjh wrap-around, shaded windows and a wet bar passage that leads to the kitchen with counter seating, pantry and outdoor balcony terrace. The diagonal hallway continues to the bedroom area with an abundance of natural light and views to the garden below. The master suite has en-suite bath and walk-in closet, while the 2 other bedrooms have a shared bath. The building allows access to the roof top deck areas is through the stairways or by adding an optional elevator. Indoor parking and storage are located on a lower level under the building. Exterior walls are finished in low maintenance wall tile system and split faced concrete masonry. The building is designed to maximize energy efficiency with ICF exterior walls, energy efficient low-E windows and a thermally designed roofing system. Great Room: 400 sf Kitchen: 180 sf Master Suite: 250 sf
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-913-2350.

Floor Plans


Floor Plan - Main Floor Plan

Full Specs & Features


Basic Features

Bedrooms : 9
Baths : 6
Stories: 3
Garages: 6

Dimension

Depth : 77'
Height : 32'
Width : 35'

Area

Total : 8818 sq/ft
Decks : 258 sq/ft
Garage : 1970 sq/ft
Lower Floor : 2140 sq/ft
Main Floor : 2140 sq/ft
Storage : 170 sq/ft
Upper Floor : 2140 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Garage Ceiling : 8'
Upper Ceiling Ft : 9'

Roof

Roof Framing : Manuf. Wood trusses
Roof Type : Flat

Exterior Wall Framing

Exterior Wall Finish : Ceramic tile, glazed curtain wall, split face CMU on ICF wall panel
Framing : Flooringw/ flat wd. trusses. Walls - 2"x wd. studs or mtl. studs.
Insulation : R-22 to R-30 rated ICF wall panels

Bedroom Features

Walk In Closet

Kitchen Features

Eating Bar
Kitchen Island
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry

Additional Room Features

Main Floor Laundry

Garage Features

Garage Under
Oversized Garage

Lot Characteristics

Suited For Narrow Lot

Outdoor Spaces

Courtyard
Grill Deck Sundeck

More

Economical To Build
Jack & Jill Bath
Wheelchair Adaptable

Energy Efficient Features

Energy Efficient Design

What's included in this plan set


See a sample plan set

All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
*See important information before purchasing

Pricing


Plan Options

PDF Set

Best Value!
$2250.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.

CAD Set

$4500.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Foundation Options

Basement

$0.00
Ideal for level lot, lower level of home partially or fully underground.

Crawlspace

$1400.00
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.

*Options with a fee may take time to prepare. Please call to confirm.

Additional Options:

Audio Video Design

$100.00
Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide

$39.00
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Home Furniture Planner

$19.00
This fun visual aid lets you peel-and-stick furniture on a generic layout to plan out spacing.

Lighting Design

$200.00
Receive an overlay sheet with suggested placement of lighting fixtures.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
